Description:
RMNTLAN008 is a wireless USB adapter fully compliant with IEEE802.11g, communicates with any device that compliant with IEEE802.11g, IEEE802.11b, or connects with wired networking through AP.
Features:
l USB interface, hot PnP supported
l TCP/ IEEE 802.11g, IEEE 802.11b supported, compliant with Wi-Fi
l IP, NDIS3, NDIS4, NetBEUI supported
l Two working modes available: Ad Hoc Mode and Infrastructure Mode
l Transmission rate up to 54Mbps covers 300m
l Network status auto detects and rate auto negotiable
l WPA, IEEE802.11x, TKIP, AES supported
l Simple configuration, monitor program available
l Supports the communication of desktop PC and notebook with WLAN
l Wireless roaming supported
◆ Specifications:
|
Standard and protocols supported |
IEEE 802.11g, IEEE 802.11b, CSMA/CA |
|
Bus Type |
USB2.0 |
|
Frequency Range |
2.4～2.4835GHz |
|
Transmission Rate |
54 Mbps, 48 Mbps, 36 Mbps, 24 Mbps, 18 Mbps, 12 Mbps, 9 Mbps, 6 Mbps, 11 Mbps, 5.5 Mbps, 2 Mbps, 1 Mbps |
|
Channels |
13 |
|
Sequence Spread |
DSSS(Direct Sequence Spread Spectrum) |
|
Data modulation |
BPSK, QPSK, CCK and OFDM(BPSK/QPSK/16-QAM/64-QAM) |
|
Transmission type |
CCK, OFDM |
|
Transmission Distance |
Up to 100m (indoor), up to 300(outdoor) |
|
Antenna Gain |
2dBi |
|
LED Indicator |
LINK/ACT(wireless network) |
|
Working Environment |
Working temperature:0ºC～40ºC;
Store temperature:-20ºC～80ºC
Working humidity :10%～95% RH Non-condensing |
|
OS supported |
Windows9x/Me/2000/NT/XP/2003 |
|
